Metal Square Weld Wire Mesh Roll is a robust metal grid product made by precise electric welding of horizontal and vertical steel wires into uniform square openings. It is available in hot-dipped galvanized, electro-galvanized and stainless steel finishes to deliver outstanding rust resistance and long service life.
Each wire intersection is firmly fused together, forming a stable, flat mesh structure that won’t deform or separate easily under daily tension and impact. Supplied in continuous rolled form for easy transportation, cutting and on-site installation, it greatly reduces construction waste and labor costs.
Key Features
Uniform square mesh holes with precise welding positioning, neat and flat mesh surface without deformation
Firm welding joints, high tensile strength, not easy to crack or fall off under impact and stretching Multiple anti-rust surface treatments, excellent corrosion resistance for outdoor long-term use
Rolled packaging design, easy to transport, store, cut and install on site
Smooth wire surface without burrs, safe for livestock and construction workers
Flexible customizable wire diameter and aperture, matching light/medium/heavy load scenarios
Item | Detailed Parameters |
|---|---|
Material Grade | Low carbon steel wire, SS304, SS316 stainless steel |
Wire Diameter | 0.4mm – 6.0mm (customizable) |
Square Mesh Aperture | 6mm×6mm, 12.5mm×12.5mm, 25mm×25mm, 50mm×50mm, 100mm×100mm |
Standard Roll Width | 0.5m, 1.0m, 1.2m, 1.5m, 2.0m |
Standard Roll Length | 10m, 20m, 30m, 50m, 100m |
Surface Treatment | Electro galvanized, hot dipped galvanized, PVC coated, stainless steel raw finish |
Welding Technology | Full automatic resistance spot welding |
Package Form | Plastic film wrapped roll, wooden pallet bulk packing |
Tolerance Standard | Wire diameter ±0.05mm, mesh hole ±1mm |
Common Applications
Construction: Wall plaster reinforcement mesh, concrete anti-crack net, building isolation barrier Agriculture & Breeding: Chicken coops, rabbit cages, livestock fence, farm crop protection net
Garden & Landscape: Yard boundary fence, plant support mesh, garden anti-animal barrier
Industrial Use: Machine safety guard screen, workshop isolation mesh, pipeline protection cover Aquaculture: Fish tank separation net, coastal breeding anti-wave mesh
Decoration & Filtration: Partition decorative mesh, simple filter grid for mechanical equipment
FAQ
Q1: What’s the difference between electro-galvanized and hot-dipped galvanized mesh?
A: Electro-galvanized mesh has thin zinc layer, suitable for indoor dry use with lower cost; hot-dipped galvanized owns thick zinc coating, strong anti-rust ability, perfect for outdoor long-term exposure.
Q2: Can this square weld wire mesh be cut freely on site?
A: Yes, the rolled mesh can be cut into any size with wire cutter, easy to adapt different construction and breeding scenes.
Q3: Is stainless steel mesh rust-proof completely near sea water?
A: 316 stainless steel performs well in coastal salt fog environment; 304 stainless steel is recommended for inland humid areas only.
Q4: What is the minimum order quantity for customized specifications?
A: Standard sizes support small MOQ; customized non-standard wire diameter or roll sizes require negotiated bulk quantity.
